Surface Igniter DS311K Whirlpool Replacement igniter is made of the same materials and specifications as the OEM requires. The igniter is CSA-approved RoHS and Reach Complaint; It comes with the Prop 65 Warning. The DS311K replaces |4391996 | AP3109449 |14211282 | 3-4970 | 3018 | 304970 | 41-311 | 41-590 | 4391996VP | AH373025 | DE351 | DE363 | EA373025 | K35-166 | K35-455 | PS373025 | WE4X750 | IGD4100SQ | LG5651XMW0 | MGDE400XW | 279311| 101M| The DS311K Whirlpool Dryer replacement igniter kit is used to light the dryer burners. The DS311K igniter comes with OEM terminals. Wire leads are 5.25″ long. the connector plug might need to be removed and spliced to the oven wiring using porcelain wire nuts. Before you begin this repair, disconnect the power source from the dryer, and shut off the gas supply.
Specifications
| Part number | DS311K |
|---|---|
| Type | dryer igniter |
| Current / voltage | ≤4.25 A @115 VAC (max 5 A @132 VAC) |
| Heat-up | 1800°F ≤100 s @115 VAC |
| Lead wires | leads 5.0 in, 18 GA UL3122 or better |
| Connector | Molex 03-09-2022 housing / 02-09-2116 pins |
| OEM / cross reference | 14211282, 279311, 3-4970, 304970, 4391996, 4391996VP, AH373025, AP3109449, DE351, DE363, EA373025, IGD4100SQ, LG5651XMW0, MGDE400XW, PS373025, WE4X750 |
Replaces: 279311, WE4X750, Z716C, 41-311, SDE364, 4391996
Installation & safety: Shut off gas and power; handle by bracket only.
Returns: 15 days new unused. See our refund and returns policy.
