Trane direct replacement 120V nitride ignitor with 4-1/2″ leads and 2-pin molex connector, mounting bracket and screws. Replaces IGN00152 and IGN00146.
Features
- OEM replacement nitride igniters for Trane
- 120V model
- OEM spec lead length, dimensions and connectors
- White high temperature Teflon™ coated leads
- Insulation 250°C Temperature rating
Specifications
- Operating Voltage
- 120 Vac, 60 Hz
- Length (with connector)
- 5.00” Lead
- Approvals
- C.S.A. approved
Specifications
| Part number | 789A-820KT1 |
|---|---|
| Type | silicon nitride igniter, 40.6 mm ring |
| Current / voltage | <4 A @115 VAC |
| Heat-up | 1800°F <17 s @115 VAC |
| Lead wires | leads 133 mm (5.24 in), 20 GA UL5128 300 V 450°C |
| Connector | Molex 19-09-2029 housing / 02-09-1117 terminals |
